532nm单纵模激光器
LLDZ532-100mw
SINGLE LONGITUDINAL MODE GREEN LASER AT 532 nm All solid state single longitudinal mode green laser at 532 nm is made features of ultra compact, long lifetime, low cost and easy operating, which is used in DNA sequencing, flow cytometry, cell sorting, optical instrument, spectrum analysis, interference, measurement, holography, brillouin scattering, physics experiment, etc.
| Wavelength (nm)波长 | 532±2 |
| Operating mode | CW |
| Output power (mW) | > 100 |
| Power stability (rms, over 4 hours) | <3% |
| Transverse mode | TEM00 |
| Longitudinal mode | Single |
| Spectral linewidth (nm) | <0.00001 |
| Coherent length (m) | >50 |
| Noise of amplitude (rms, 1Hz~20MHz) | <0.5% |
| M2 factor | <1.2(<1.1 optional) |
| Beam diameter at the aperture (1/e2, mm) | <1.5 |
| Beam divergence, full angle (mrad) | <1.2 |
| Polarization ratio | >100:1, Vertical±5 degree (Horizontal Optional) |
| Warm-up time (minutes) | <10 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 24.8 |
| Operating temperature (℃) | 15~35 |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
