552nm激光器
LL552-300mw
LD PUMPED ALL-SOLID-STATE GREEN LASER DPSS green laser at 552nm is made features of ultra compact, long lifetime and easy operating, which is used in measurement, medical treatment, scientific research, etc.
| Part number | LL552-300mw |
| Wavelength (nm) | 552± 1 |
| Operating mode | CW |
| Output power (mW) | 1-300 |
| Power stability (rms, over 4 hours) | < 10%, <5%, <3% |
| Transverse mode | Near TEM00 |
| M2 factor | <2.0 |
| Beam diameter at the aperture ( 1/e2, mm) | <2.0 |
| Beam divergence, full angle (mrad) | <2.0 |
| Polarization Ratio | > 100:1, (Horizontal or Vertical Optional) |
| Warm-up time (minutes) | <5 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating Temperature (°C) | 10-35 |
| Modulation option | TTL on/off, 1Hz- 1kHz, 1kHz- 10kHz |
| Power supply (90-264VAC) | PSU-H-LED |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
