612nm激光器
LL612-100mw
LD PUMPED ALL-SOLID-STATE RED LASER DPSS laser at 612nm features ultra compact, long lifetime and easy operating, it is widely used in communication, medical treatment, scientific research, etc.
| Wavelength (nm) | 612±1 |
| Operating mode | CW |
| Output power (mW) | > 1, 10, 50, … , 100 |
| Power stability (rms, over 4 hours) | <3%, <5% |
| Transverse mode | Near TEM00 |
| Beam divergence, full angle (mrad) | <2 |
| Beam diameter at the aperture ( 1/e2,mm) | ~4 |
| Polarization ratio | > 100:1 |
| Beam height from base plate (mm) | 100 |
| Warm-up time (minutes) | < 10 |
| Operating temperature (C) | 15~30 |
| Power supply (90-264VAC) | PSU-W-FDA |
| Expected lifetime (hours) | 10000 |
| Warranty period | 1 year |
