257nm激光器
LLQ257-15mw
LLQ257-15mw全固态257nm的紫外激光器广泛用于紫外光固化，微电子，光盘雕刻，激光医疗，科学实验等
| Wavelength (nm) | 257± 1 | |
| Operating mode | Frequency conversion of Q-switched pulsed laser | |
| Max average power (mW)* | 1~ 15 | |
| Single pulse energy ( µJ) | 0. 1~4 | |
| Pulse duration (ns) | ~5 | |
| Peak power (kW) | 0.2~0.8 | |
| QCW | Between 2k-5kHz. | |
| Ave power stability (over 4 hours) | < 10%, <5%,<3% | |
| Transverse mode | Near TEM00 | |
| M2 factor | <2.0 | |
| Beam diameter at the aperture (mm) | Elliptical (4:1), Beam spot 0.5*2mm | |
| Polarization ratio | >50:1, (Horizontal or Vertical Optional) | |
| Warm-up time (minutes) | <5 | |
| Beam height from base plate (mm) | 70 | |
| Operating temperature (°C) | 10~35 | |
| Power supply (90-264VAC) | PSU-H-LED/PSU-H-FDA | |
| Warranty | 1 year | |
