320nm脉冲激光器
LLQ320-60mw
| Wavelength (nm)波长 | 320± 1 |
| Operating mode工作方式 | Acousto-Optic Q-switched |
| Average power (W)平均功率 | 1~80 (60mW@ 10kHz,80mW@20kHz) |
| Average power (W) = Single pulse energy (mJ) * Rep. rate (kHz) | |
| Single pulse energy (µJ)单脉冲能量 | 1~6 (6μJ @ 10kHz,4μJ @20kHz) |
| Rep. rate (kHz)频率 | 10~20 |
| Pulse duration (ns)脉宽 | <30@ 10~20kHz, varies from power and repetition. |
| Peak power (KW)峰值功率 | 0-0.2(0.2kW@ 10kHz) |
| Ave power stability (over 4 hours)功率稳定性 | <3%, <5% |
| Warm-up time (minutes)上升时间 | < 10 |
| Beam divergence, full angle (mrad)发散角 | <2 |
| Beam diameter at the aperture ( 1/e2,mm)光斑尺寸 | ~ 1.5 |
| Beam height from base plate (mm) | On request |
| Cooled method制冷 | Water cooled |
| Operating temperature (C)工作温度 | 10~35 |
| Power supply (220/ 110VAC)供电 | On request |
| Expected lifetime (hours)寿命 | 10000 |
| Warranty period保修 | 1 year |
