性能特点
可以低温冷却到-100℃,热电冷却到-60℃;
多种读出速度可选,100kHz-2MHz;
低至3e- RMS的读出噪声;
高动态范围;
能处理6k×6k,15μm pixel的传感器,典型配置是4k×4k,15μm pixel的传感器;
1-4个读出端口;
光纤输出,并可直接与CCD耦合;
相机可安装快门,快门由相机本身驱动;
光纤通信接口;
SI图像软件可用于对相机的控制、数据操作和归档。
相机参数
Cryo cooling | One compressor housed in supplied cabinet with braided stainless steel lines running to camera head, up to 100’ |
Thermoelectric Cooling | One liter per minute @ 20°C water cooling required for most configurations and CCD temperatures down to –60° for most 4kx4k sensors |
Window details | Many AR coatings available with custom order.Typical Broadband specs: <1% Reflectivity per surface, 450- 800nm |
Window heater | Adhered to front window for cryo versions |
CCD to mounting surface | ~20mm, depends on CCD and options |
Read speeds | Software selectable, customizable |
Camera weight | About 12lbs, depending on options |
