Innovative Photonic Solutions成立于2003年，致力于开发和生产高性能半导体激光器，公司的核心竞争力在于外延晶体结构的设计与制造、晶圆制造、设备测试、可靠性高的包装,和集成系统的设计。

激光器型号
Product ID	FWHM Spectral Width	Ouput Power (mW)	Output Configuration or Connector	Integral Laser Line Filter	Integral Photodiode	Data Sheet
405nm Single Mode
I0405SB0045B	<100 kHz	45	Open Beam	Yes	Yes	14 Pin Data sheet.pdf
I0405SD0030B-IS	<100MHz, <0.2 pm, <0.005 cm-1	30 with integral dual-stage isolator	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-type Data Sheet.pdf
I0405SD0045B	<100MHz, <0.2 pm, <0.005 cm-1	45	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-type Data Sheet.pdf
I0405SR0030B-IS	<100MHz, <0.2 pm, <0.005 cm-1	30 with integral dual-stage isolator	Open Beam	Yes	Yes	R-type Module.pdf
I0405SR0045B	<100MHz, <0.2 pm, <0.005 cm-1	45	Open Beam	Yes	Yes	R-type Module.pdf
I0405SH0030B-IS-TH-L	<100MHz, <0.2 pm, <0.005 cm-1	30 with integral dual-stage isolator	Open Beam	Yes - Dual Filter Pack	Yes	Tethered Head H-type Data Sheet.pdf
I0405SH0045B-TH-L	<100MHz, <0.2 pm, <0.005 cm-1	45	Open Beam	Yes - Dual Filter Pack	Yes	Tethered Head H-type Data Sheet.pdf
532nm Multi Mode laser
I0532SL0100MF	<0.05 nm	100	FC/PC	No	No	532 nm L-Type Data Sheet
I0532SL0100MS	<0.05 nm	100	SMA	No	No	532 nm L-Type Data Sheet
633nm Single Mode laser
I0633S50015B	<100 kHz	15	Open Beam	Yes	Yes	TO-56 Data sheet.pdf
I0633S50035B		35
I0633S50050B		50
I0633SB0015B	<100 kHz	15	Open Beam	Yes	Yes	14-pin Data Sheet.pdf
I0633SB0035B		35
I0633SB0050B		50
I0633SD0015B	<100MHz, <0.2 pm, <0.005 cm-1	15	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-type Data Sheet.pdf
I0633SD0035B		35
I0633SD0050B		50
I0633SD0010B-IS	<100MHz, <0.2 pm, <0.005 cm-1	10 with integral dual stage isolator	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-Type Data Sheet.pdf
I0633SD0030B-IS	<100MHz, <0.2 pm, <0.005 cm-1	30 with integral dual stage isolator	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-Type Data Sheet.pdf
I0633SR0035B-IS	<100MHz, <0.2 pm, <0.005 cm-1	10 with integral dual stage isolator	Open Beam	Yes	Yes	R-type Module.pdf
I0633SR0035B-IS		30 with integral dual stage isolator
I0633SR0030B		15
I0633SR0035B		35
I0633SR0050B		50
I0633SH0010B-IS-TH-L	<100MHz, <0.2 pm, <0.005 cm-1	10 with integral dual stage isolator	Open Beam	Yes - Dual Filter Pack	Yes	Tethered Head H-type Data Sheet.pdf
I0633SH0030B-IS-TH-L		30 with integral dual stage isolator
I0633SH0015B-TH-L		15
I0633SH0035B-TH-L		35
I0633SH0050B-TH-L		50
638nm Single Mode laser
I0638S50035B	<100 kHz	35	Open Beam	Yes	Yes	TO-56 Data sheet.pdf
I0638S50060B	<100 kHz	60	Open Beam	Yes	Yes	TO-56 Data sheet.pdf
I0638SB0035B	<100 kHz	35	Open Beam	Yes	Yes	14-pin Data Sheet.pdf
I0638SB0060B	<100 kHz	60	Open Beam	Yes	Yes	14-pin Data Sheet.pdf
I0638SD0035B	<100MHz, <0.2 pm, <0.005 cm-1	35	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-type Data Sheet.pdf
I0638SD0060B	<100MHz, <0.2 pm, <0.005 cm-1	60	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-type Data Sheet.pdf
I0638SD0035B-IS	<100MHz, <0.2 pm, <0.005 cm-1	35 with integral dual stage isolator	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-Type Data Sheet.pdf
I0638SR0035B-IS	<100MHz, <0.2 pm, <0.005 cm-1	35 with integral dual stage isolator	Open Beam	Yes	Yes	R-type Module.pdf
I0638SR0035B		35
I0638SR0060B		60
I0638SH0035B-IS-TH-L	<100MHz, <0.2 pm, <0.005 cm-1	35 with integral dual stage isolator	Open Beam	Yes - Dual Filter Pack	Yes	Tethered Head H-type Data Sheet.pdf
I0638SH0035B-TH-L		35
I0638SH0060B-TH-L		60
647nm Multi-Mode laser
I0647MB0150B	<0.15	150	Open Beam	Yes	Yes	14-pin Data Sheet.pdf
I0647MB0150M	<0.15	150	Unterminated	No	Yes	14-pin Data Sheet.pdf
I0647MB0150MF			FC/PC
I0647MB0150MS			SMA905
I0647MU0150MF	<0.15	150	FC/PC	No	Yes	U-type Data Sheet.pdf
I0647MU0150MS	<0.15	150	SMA905	No	Yes	U-type Data Sheet.pdf
I0647MM0150MF	<0.15	150	FC/PC	No	Yes	M-type Data Sheet.pdf
I0647MM0150MS	<0.15	150	SMA905	No	Yes	M-type Data Sheet.pdf
660nm Single Mode laser
I0660S50050B	<100 kHz	50	Open Beam	Yes	No	TO-56 Data sheet.pdf
I0660SB0050B	<100 kHz	50	Open Beam	Yes	Yes	14-pin Data Sheet.pdf
I0660SD0050B	<100MHz, <0.2 pm, <0.005 cm-1	50	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-type Data Sheet.pdf
I0660SR0050B	<100MHz, <0.2 pm, <0.005 cm-1	50	Open Beam	Yes	Yes	R-type Module.pdf
I0660SH0050B-TH-L	<100MHz, <0.2 pm, <0.005 cm-1	50	Open Beam	Yes - Dual Filter Pack	Yes	Tethered Head H-type Data Sheet.pdf
785nm Single Mode laser
I0785S50100B	<100 kHz	100	Open Beam	Yes	No	TO-56 Data sheet.pdf
I0785SB0100B	<100 kHz	100	Open Beam	Yes	Yes	14-pin Data Sheet.pdf
I0785SB0050P	<100 kHz	50	Unterminated PM Fiber	No	Yes	14-pin Data Sheet.pdf
I0785SB0050PA			PM Fiber with FC/APC
I0785SB0050S			Unterminated SM Fiber
I0785SB0050SA			SM Fiber with FC/APC
I0785SD0090B-IS	<100MHz, <0.2 pm, <0.005 cm-1	90 with integral dual stage isolator	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-Type Data Sheet.pdf
I0785SD0100B	<100MHz, <0.2 pm, <0.005 cm-1	100	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-Type Data Sheet.pdf
I0785SU0050PA	<100MHz, <0.2 pm, <0.005 cm-1	50	Single Mode PM Fiber, Panda type with FC/APC connector	No	Yes	U-Type Data Sheet.pdf
I0785SU0050SA	<100MHz, <0.2 pm, <0.005 cm-1	50	Single Mode Fiber with FC/APC connector	No	Yes	U-Type Data Sheet.pdf
I0785SR0090B-IS1	<100MHz, <0.2 pm, <0.005 cm-1	90 with integral dual stage isolator	Open Beam	Yes	Yes	R-Type Module.pdf
I0785SR0100B1	<100MHz, <0.2 pm, <0.005 cm-1	100	Open Beam	Yes	Yes	R-Type Module.pdf
I0785SL0050PA	<100MHz, <0.2 pm, <0.005 cm-1	50	Single Mode PM Fiber, Panda type with FC/APC connector	No	Yes	L-Type Module Data Sheet.pdf
I0785SL0050SA	<100MHz, <0.2 pm, <0.005 cm-1	50	Single Mode Fiber with FC/APC connector	No	Yes	L-Type Module Data Sheet.pdf
I0785SH0090B-IS-TH-L	<100MHz, <0.2 pm, <0.005 cm-1	90 with integral dual stage isolator	Open Beam	Yes - Dual Filter Pack	Yes	Tethered Head H-type Data Sheet.pdf
I0785SH0100B-TH-L	<100MHz, <0.2 pm, <0.005 cm-1	100	Open Beam	Yes - Dual Filter Pack	Yes	Tethered Head H-type Data Sheet.pdf
I0785SR0500B-MOPA	<100MHz, <0.2 pm, <0.005 cm-1	>500 mW	Open Beam	Yes	Yes	MOPA Datasheet.pdf
I0785SR0500B-MOPA		(1 W available)	Open Beam	Yes	Yes	MOPA Datasheet.pdf
I0785SM0300PA-MOPA		>300 mW	Single Mode PM Fiber, Panda type with FC/APC connector	No	Yes	MOPA Datasheet.pdf
785nm Multi-Mode laser
0785MB0500B	<0.15	500	Open Beam	Yes	Yes	14-pin Data Sheet.pdf
I0785MB0350M	<0.15	350	Unterminated	No	Yes	14-pin Data Sheet.pdf
I0785MB0350MF			FC/PC
I0785MB0350MS			SMA905
I0785MB0350M-NL	<0.07	350	Unterminated
I0785MB0350MF-NL			FC/PC
I0785MB0350MS-NL			SMA905
I0785MB0600M	<0.15	600	Unterminated
I0785MB0600MF			FC/PC
I0785MB0600MS			SMA905
I0785MU0350MF	<0.15	350	FC/PC	No	Yes	U-Type Data Sheet.pdf
I0785MU0350MS	<0.15	350	SMA905
I0785MU0350MF-NL	<0.07	350	FC/PC
I0785MU0350MS-NL	<0.07	350	SMA905
I0785MU0500MF	<0.15	500	FC/PC
I0785MU0500MS	<0.15	500	SMA905
I0785MM0350MF	<0.15	350	FC/PC	No	Yes	M-Type Data Sheet.pdf
I0785MM0350MS		350	SMA905
I0785MM0500MF		500	FC/PC
I0785MM0500MS		500	SMA905
I0785IP0350B-001-TH	<0.15	350	SMA905, Custom Rectangular Core (FC/PC Available upon request)	Yes	No	Integrated Raman Probe Data Sheet.pdf
808nm Single Mode laser
I0808S50100B	<100 kHz	100	Open Beam	Yes	No	TO-56 Data sheet.pdf
I0808SB0100B	<100 kHz	100	Open Beam	Yes	Yes	14-pin Data Sheet.pdf
I0808SB0050P	<100 kHz	50	Unterminated PM Fiber	No	Yes	14-pin Data Sheet.pdf
I0808SB0050PA			PM Fiber with FC/APC
I0808SB0050S			Unterminated SM Fiber
I0808SB0050SA			SM Fiber with FC/APC
I0808SD0100B	<100MHz, <0.2 pm, <0.005 cm-1	100	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-Type Data Sheet.pdf
I0808SU0050PA	<100MHz, <0.2 pm, <0.005 cm-1	50	Single Mode PM Fiber, Panda type with FC/APC connector	No	Yes	U-Type Data Sheet.pdf
I0808SU0050SA	<100MHz, <0.2 pm, <0.005 cm-1	50	Single Mode Fiber with FC/APC connector	No	Yes	U-Type Data Sheet.pdf
I0808SR0100B	<100MHz, <0.2 pm, <0.005 cm-1	100	Open Beam	Yes	Yes	R-Type Module.pdf
I0808SL0050PA	<100MHz, <0.2 pm, <0.005 cm-1	50	Single Mode PM Fiber, Panda type with FC/APC connector	No	Yes	L-Type Module Data Sheet.pdf
I0808SL0050SA	<100MHz, <0.2 pm, <0.005 cm-1	50	Single Mode Fiber with FC/APC connector	No	Yes	L-Type Module Data Sheet.pdf
808nm Multi-Mode laser
I0808MB0500B	<0.15	500	Open Beam	Yes	Yes	14-pin Data Sheet.pdf
I0808MB0350M	<0.15	350	Unterminated	No	Yes	14-pin Data Sheet.pdf
I0808MB0350MF			FC/PC
I0808MB0350MS			SMA905
I0808MB0350M-NL	<0.07	350	Unterminated
I0808MB0350MF-NL			FC/PC
I0808MB0350MS-NL			SMA905
I0808MB0600M	<0.15	600	Unterminated
I0808MB0600MF			FC/PC
I0808MB0600MS			SMA905
I0808MU0350MF	<0.15	350	FC/PC	No	Yes	U-Type Data Sheet.pdf
I0808MU0350MS	<0.15	350	SMA905
I0808MU0350MF-NL	<0.07	350	FC/PC
I0808MU0350MS-NL	<0.07	350	SMA905
I0808MU0500MF	<0.15	500	FC/PC
I0808MU0500MS	<0.15	500	SMA905
I0808MM0350MF	<0.15	350	FC/PC	No	Yes	M-Type Data Sheet.pdf
I0808MM0350MS		350	SMA905
I0808MM0500MF		500	FC/PC
I0808MM0500MS		500	SMA905
830nm Single Mode laser
I0830S50100B	<100 kHz	100	Open Beam	Yes	No	TO-56 Data sheet.pdf
I0830SB0100B	<100 kHz	100	Open Beam	Yes	Yes	14-pin Data Sheet.pdf
I0830SB0050P	<100 kHz	50	Unterminated PM Fiber	No	Yes	14-pin Data Sheet.pdf
I0830SB0050PA			PM Fiber with FC/APC
I0830SB0050S			Unterminated SM Fiber
I0830SB0050SA			SM Fiber with FC/APC
I0830SD0100B	<100MHz, <0.2 pm, <0.005 cm-1	100	Open Beam	Yes - Dual Filter Pack	Linear Tracking Photodiode	D-Type Data Sheet.pdf
I0830SU0050PA	<100MHz, <0.2 pm, <0.005 cm-1	50	Single Mode PM Fiber, Panda type with FC/APC connector	No	Yes	U-Type Data Sheet.pdf
I0830SU0050SA	<100MHz, <0.2 pm, <0.005 cm-1	50	Single Mode Fiber with FC/APC connector	No	Yes	U-Type Data Sheet.pdf
I0830SR0100B	<100MHz, <0.2 pm, <0.005 cm-1	100	Open Beam	Yes	Yes	R-Type Module.pdf
I0830SL0050PA	<100MHz, <0.2 pm, <0.005 cm-1	50	Single Mode PM Fiber, Panda type with FC/APC connector	No	Yes	L-Type Module Data Sheet.pdf
I0830SL0050SA	<100MHz, <0.2 pm, <0.005 cm-1	50	Single Mode Fiber with FC/APC connector	No	Yes	L-Type Module Data Sheet.pdf
830nm Multi-Mode laser
I0830MB0500B	<0.15	500	Open Beam	Yes	Yes	14-pin Data Sheet.pdf
I0830MB0350M	<0.15	350	Unterminated	No	Yes	14-pin Data Sheet.pdf
I0830MB0350MF			FC/PC
I0830MB0350MS			SMA905
I0830MB0350M-NL	<0.07	350	Unterminated
I0830MB0350MF-NL			FC/PC
I0830MB0350MS-NL			SMA905
I0830MB0600M	<0.15	600	Unterminated
I0830MB0600MF			FC/PC
I0830MB0600MS			SMA905
I0830MU0350MF	<0.15	350	FC/PC	No	Yes	U-Type Data Sheet.pdf
I0830MU0350MS	<0.15	350	SMA905
I0830MU0350MF-NL	<0.07	350	FC/PC
I0830MU0350MS-NL	<0.07	350	SMA905
I0830MU0500MF	<0.15	500	FC/PC
I0830MU0500MS	<0.15	500	SMA905
I0830MM0350MF	<0.15	350	FC/PC	No	Yes	M-Type Data Sheet.pdf
I0830MM0350MS		350	SMA905
I0830MM0500MF		500	FC/PC
I0830MM0500MS		500	SMA905
976nm Single Mode laser
	<100 kHz	400	Open Beam	N/A	Yes	14-pin Data Sheet.pdf
I0976SB0750B	<100 kHz	750	Open Beam	N/A	Yes	14-pin Data Sheet.pdf
I0976SB0220P	<100 kHz	220	PM Fiber, Panda type	Unterminated	Yes	14-pin Data Sheet.pdf
I0976SB0220PA		220		FC/APC
I0976SB0500P		500		Unterminated
I0976SB0500PA		500		FC/APC
I0976SU0220SA	<100MHz, <0.2 pm, <0.005 cm-1	220	Single Mode Fiber	FC/APC	Yes	U-type Data Sheet.pdf
I0976SU0220PA		220	PM Fiber, Panda type
I0976SU0500SA		500	Single Mode Fiber
I0976SU0500PA		500	PM Fiber, Panda type
I0976SR0400B	<100 MHz, <0.2 pm, <0.005 cm-1	400	Open Beam	N/A	Yes	R-type Module.pdf
I0976SR0750B	<100 MHz, <0.2 pm, <0.005 cm-1	750	Open Beam	N/A	Yes	R-type Module.pdf
I0976SL0220SA	<100MHz, <0.2 pm, <0.005 cm-1	220	Single Mode Fiber	FC/APC	Yes	L-type Module Data Sheet.pdf
I0976SL0220PA		220	PM Fiber, Panda type
I0976SL0500SA		500	Single Mode Fiber
I0976SL0500PA		500	PM Fiber, Panda type
I0976SL0400B-TH	<100MHz, <0.2 pm, <0.005 cm-1	400	Open Beam	N/A	Yes	Tethered Head H-type Data Sheet.pdf
I0976SL0750B-TH	<100MHz, <0.2 pm, <0.005 cm-1	750	Open Beam	N/A	Yes	Tethered Head H-type Data Sheet.pdf
976nm Multi-Mode laser
I0976MB4000M	<0.15	4000	105 micron core Multi-mode Fiber (62.5 micron core available upon request, but it will affect output power)	Unterminated, FC/PC, SMA905	Yes	14-pin Data Sheet.pdf
I0976MB4000MF
or
I0976MB4000MS
I0976MB6000M	<0.15	6000
I0976MB6000MF
or
I0976MB6000MS
1053nm Single Mode laser
I1053SB0050P-IS	<100kHz	50	PM Fiber	None	No
I1053SB0050PA-IS		50		FC/APC
I1053SB0100P		100		None
I1053SB0100PA		100		FC/APC
I1053SB0300P		300		None
I1053SB0300PA		300		FC/APC
I1053SD0100B	<100MHz, <0.2 pm, <0.005 cm-1	100	Open Beam	N/A	Yes - Dual Filter Pack
I1053SU0050PA-IS	<100MHz, <0.2 pm, <0.005 cm-1	50	PM Fiber	FC/APC	No
I1053SU0100PA		100
I1064SU0300PA		300
I1053SL0050PA-IS	<100MHz, <0.2 pm, <0.005 cm-1	50	PM Fiber	FC/APC	No
I1053SL0100PA		100
I1053SL0300PA		300
1064nm Single Mode laser
I1064S50150B	<100kHz	150	Open Beam	None	Yes
I1064SB0500B		500	Open Beam	None	Yes
I1064SB0050P-IS		50	PM Fiber	None	No
I1064SB0050PA-IS		50		FC/APC
I1064SB0120P		120		None
I1064SB0120PA		120		FC/APC
I1064SB0300P		300		None
I1064SB0300PA		300		FC/APC
I1064SD0150B	<100MHz, <0.2 pm, <0.005 cm-1	150	Open Beam	N/A	Yes - Dual Filter Pack
I1064SU0050PA-IS	<100MHz, <0.2 pm, <0.005 cm-1	50	PM Fiber	FC/APC	No
I1064SU0120PA		120
I1064SU0300PA		300
I1064SL0050PA-IS	<100MHz, <0.2 pm, <0.005 cm-1	50	PM Fiber	FC/APC	No
I1064SL0120PA		120
I1064SL0300PA		300
1064nm Multi-Mode
I1064MB0800B	<0.15	800	Open Beam	Yes	Yes	14-pin Data Sheet.pdf
I1064MB0350M	<0.15	350	Unterminated	No	Yes	14-pin Data Sheet.pdf
I1064MB0350MF			FC/PC
I1064MB0350MS			SMA905
I1064MB0350M-NL	<0.07	350	Unterminated
I1064MB0350M-NL			FC/PC
I1064MB0350MF-NL			FC/PC
I1064MB0350MS-NL			SMA905
I1064MB0600M	<0.15	600	Unterminated
I1064MB0600MF			FC/PC
I1064MB0600MS			FC/PC
I1064MB0600MS			SMA905
I1064MU0350MF	<0.15	350	FC/PC	No	Yes	U-type Data Sheet.pdf
I1064MU0350MS	<0.15		SMA905
I1064MU0350MF-NL	<0.07		FC/PC
I1064MU0350MS-NL	<0.07		SMA905
I1064MU0500MF	<0.15	500	FC/PC
I1064MU0500MS	<0.15	500	SMA905
I1064MM0350MF	<0.15	350	FC/PC	No	Yes	M-type Data Sheet.pdf
I1064MM0350MS		350	SMA905
I1064MM0500MF		500	FC/PC
I1064MM0500MS		500	SMA905
1064.x Single Mode laser
I1064.XSB0050P-IS	<100kHz	50	PM Fiber	None	No
I1064.XSB0050PA-IS		50		FC/APC
I1064.XSB0120P		120		None
I1064.XSB0120PA		120		FC/APC
I1064.XSB0300P		300		None
I1064.XSB0300PA		300		FC/APC
