Description

The 1550nm narrow linewidth picosecond Pulsed Fiber Laser NPFL1550 is an all-fiber polarization maintaining mode-locked fiber laser based on semiconductor saturation absorption mirror. The pulsed laser provides an effective management interface for user to control key operating parameters. It presents RS-232 interface flexibly, ensuring the connectivity with customer’s control system. It is controlled by automatic power control mode (APC mode) with narrow pulsewidth, narrow spectral linewidth and stable output power. The center wavelength can be fast tuned by temperature.

Features

Narrow spectral linewidth

Up to 20mW output power

Fast center wavelength tuning

Reliable self-start

20MHz frequency

Extinction ratio＞20dB

Automatic power control (APC)

Applications

Research

Measurement
