Description

The 1550nm picosecond Pulsed Fiber Laser is an all-fiber polarization maintaining mode-locked fiber laser based on semiconductor saturation absorption mirror. The pulsed laser provides an effective management interface for user to control key operating parameters. It presents RS-232 interface flexibly, ensuring the connectivity with customer’s control system. It is controlled by automatic power control mode (APC mode) with narrow pulsewidth and stable output power.

Features

Narrow pulsewidth

Reliable self-start

MHz frequency

Extinction ratio>=20dB

Automatic power control (APC)
