Description

DWDM EDFA series of amplifier are especially designed for hydrophone system, DWDM subsystems, FTTx, CATV, FDC and HFC analog amplification applications that require high reliability.

Both input and output signals are sampled and monitored with a feedback circuit. APC (automatic power control), AGC (automatic gain control) and ACC (automatic current control) circuits are designed into the amplifier to ensure high output power stability and reliability. Based on integrated power monitoring circuits, this amplifier features a RS-232 interface enabling connectivity to customer’s control system.

Features

Low noise figure

Highly reliable laser diode pumps

High stability and reliability

Wide operating temperature range

Low power consumption

RS-232 for control and monitoring

Applications

Analog and digital CATV systems

Hydrophone system

LANs and WANS

In-line amplification

DWDM subsystems

FTTx

Free space communication
