Description

YEDFA-MP series of high power fiber amplifiers are especially designed for FTTx, CATV, FDC and HFC analog amplification applications those require high reliability. Compared to conventional amplifiers, these modules are more compact, powerful, stable and reliable

This line of high power fiber amplifier features a dual stage amplification configuration, pre-amplifier and power amplifier and the use of selected multi-channel splitters with extremely low IL and high reliability

Both input and output signals are sampled and monitored with a feedback circuit. ACC (automatic current control) and APC (automatic power control) circuits are designed into the amplifier to ensure high stability and reliability of output power. Standard user-friendly RS-232 interface enables reliable connectivity with customer’s control system

Features

Low noise figure

Optional output configurations: 19dBm * 32 ports, 20dBm * 24 ports, 22dBm * 16 ports, 26dBm * 8 ports,29dBm * 4 ports,  33dBm * 2 ports or 37dBm * 1 port, etc

Highly reliable laser diode pumps

High stability and reliability based on multi-mode pumping and fiber combiner technology

Wide operating temperature range

Applications

Test and Measurement

Analog CATV transmission systems

Data & Voice optical transmission systems

Optical distribution systems

FTTx

Free space communication
