Description

The YEDFA-CA-EM-C-XX fiber amplifier series are highly reliable amplifiers especially designed for FTTx, CATV, FDC and HFC analog applications. Compared with conventional amplifiers, these modules are more compact, powerful and have higher reliability and stability.

The high power fiber amplifiers are based on two stages amplification configuration, pre-amplifier and power amplifier. Both input and output signals are monitored with feedback circuit. ACC(automatic current control), APC(automatic power control) and AGC (automatic gain control) circuits are employed to ensure the high stability and reliability of output power. Integrated power monitors inside enables ease of operation via the fesatured RS-232 interface linked to customer's control system.

Features

Compact size: 164x85x18mm

Wide operating temperature range

High stability and reliability based on multi-mode pump and fiber combiner technology

RS-232 interface

Low noise figure

Applications

Data transmission

Power actuator

Measurement for optical devices and system

Detection for gas absorption

Analog CATV long distance transmission

Video optical transmission system

Optical distributing system

In-line Amplification

FTTx
