Description

This line of high power fiber amplifier combiners features a dual stage amplification configuration, pre-amplifier and power amplifier and the use of select multi-channel splitters with extremely low IL and high reliability.

Both input and output signals are sampled and monitored with a feedback circuit. ACC (automatic current control) and APC (automatic power control) circuits are designed into the amplifier to ensure high stability and reliability of output power. Standard user-friendly RS-232 interface enables reliable connectivity with customer’s control system.

Features

Low noise figure

Optional output configurations: 33dBm * 1 port, 28dBm * 2 ports, 25dBm * 4 ports, 22dBm * 8 ports, 18dBm * 16ports etc

Highly reliable laser diode pumps

High stability and reliability based on multi-mode pumping and fiber combiner technology

Wide operating temperature range

Applications

Test and Measurement

Analog CATV transmission systems

Data & Voice optical transmission systems

Optical distribution systems

FTTx

Free space communication
