Focal Length

110 mm

f/#

3.9

Max Resolution

<1nm w/1200G/mm grating and standard slits

Wavelength Precision

0.2

Wavelength Accuracy

±0.06

Slewing Speed

>100nm/second

Stray Light

<10-5

Slits

Standard Set   includes; 0.125mm, 0.15mm, 0.30mm, 0.6mm, 1.2mm and 2.4mm x 4.0mm

Gratings

One to two gratings. (30 x 30mm) must be purchased

Dimensions

5.21”×3.27”×3.12” (13.2×8.3×7.9cm)

Control connector

RS232
