Wavelength (nm) 波长

532

Output power (mW) 输出功率

10,20,30.40.50.100

Transverse mode 光斑模式

TEM00

Operating mode 工作模式

CW,

Longitudinal mode纵模

Single

Power stability (rms, over 4 hours) 功率稳定性

<1%

<3%

<5%

M2 factor M2因子

<1.1

Beam divergence, full angle (mrad) 发散角（全角）

<1.2

Beam waist (mm)束腰直径

<1.5

Spectral line width (nm) 线宽

<0.00001

Coherent length(m)相干长度

＞50

Polarization 偏振比

100:1

Point stability after warm-up(mrad) 光斑指向稳定性

<0.05

Operating temperature (℃) 工作温度

0 - 40

Warm-up time (minutes) 预热时间

<10

Expected life time 寿命

10000

Warranty time 保修期

1 year
