| 型号/Model No. | LSR589NL |
| 波长/Wavelength | 589+/-0.5nm |
| 输出功率/Output Power | 1, 5,… 40mW |
| 光斑模式/Spatial Mode | TEM00 |
| 工作方式/Operation Mode | CW or Modulation |
| 瞄准稳定性/Pointing Stability | <0.05 mrad |
| 光束直径/Beam Diameter(1/e2) | <2.5 mm |
| 光束发散角/Beam Divergence(full angle) | <1.5 mrad |
| 光束高度/Beam Height | 25mm |
| 功率稳定性/Power Stability | <±5% per 2 hrs |
| 温度稳定方式/Temperature Stabilizing | TEC |
| 预热时间/Warm Up Time | <5 minutes |
| 光束质量/Beam Quality (M2) | <2 |
| 使用寿命/MTTF | 10,000 hrs |
| 激光器尺寸/Laser head dimensions | 100(L)x40(W)x50(H)mm3 (fan adds height) |
| 配套电源/Power Supply | A. OEM type |
| LSR-PS-NI: 100(L)x70(W)x55(H)mm3 |
| AC/DC PSU: 85~265V 50/60Hz input |
| B. Lab type |
| LSR-PS-IIS: 104(W)x128(D)x89(H)mm3 |
| 85~265V 50/60Hz input |
| LSR-PS-II: 179(W)x148(D)x56(H)mm3 |
| 调制频率/Modulation | 0~30khz Analog or TTL |
