Detector

Extended type InGaAs

(uncooled)

Extended type InGaAs

2-stage TE-cooled

Spectral range

0.9−2.6μm (11000−3850cm-1)

0.9−2.5μm (11000−4000cm-1)

Interferometer type

Permanently   aligned with dual retro-reflector

Internal reference laser

Solid-state   795nm

Resolution

4   or 8 cm-1 (user selectable)

Minimum measurement cycle time

1   sec

Signal-to-noise ratio (SNR)

>30’000:1i

Wave-number repeatability

<20   PPM

Optical fiber input

SMA   905 connector, up to 1mm fiber core diameter, NA=0.25

Communication interface

USB   2.0

Power requirements

7.5-12V   (1-6W depending on versions)

Software interface

Windows   7/10 software

Operating temperature / humidity

5   to 35oC / non condensing

Storage temperature

-10   to 60oC

Dimensions

180mm   x 126mm x 78mm

Weight

1.7   KG
