探测器

SONY ILX

Pixel: 2048
Sensing 像素尺寸: 14µm x 200µm
Sensitivity: 30 V/mJ/cm²

光谱分辨率

1.0 to 10nm depending on the slit and grating choices

光谱范围

900 - 1650nm

光谱仪 f#

3.5

光纤接口

SMA 905 or FC standard

杂散光

better than 0.001

狭缝的选择

10, 25, 50, 100, 200, 400µm

电脑接口

USB 1.1 / 2.0 16-bit (support up to 8 multi-channel configuration)

软件

Windows 98/Me/2000/XP/VISTA/Win7/Win8.1/Win10 (both 32/64bit)

SM32Pro & SM32Pro MX (free with spectrometer)
Includes DLL libraries and SDKs for easy custom application development

尺寸(inches)

4.72H x 3.74W x 2.36D inches

重量

1.5lbs

暗噪声RMS

< 60 RMS counts in 16bit @ 35msec integration time

信噪比

250:1

最小积分时间

1msec

触发模式

Free Run Mode
External 触发模式

滤波器选择

n/a

探测器s

PbS
Peak Detectivity: 1 x 10¹¹cm Hz ^0.5W^-1

PbSe
D*: 1 x 10¹⁰cm Hz ^0.5W^-1

Pixels: 256
Sensing 像素尺寸: 45µm x 450µm
Pixel Clock: 2MHz (max.) for 4MHz data output
Linearity: > 90%
Response Uniformity (peak to peak): ±10% of array single mean

光谱范围

1.0 - 3.0µm

1.5 - 5.0µm

光谱分辨率

10 to 30nm depending on the slit and grating (covering wavelength choices)

光谱仪 f#

3.5

光纤接口

SMA 905 or FC standard

杂散光

Better than 0.1%

最小积分时间

0.01 - 200ms (on board)

狭缝的选择

10, 25, 50, 100µm (default: 25µm)

TEC制冷温度

-15°C ARO (default)
down to -20°C ARO is possible

电脑接口

USB 1.1 / 2.0 16-bit

供电信息

Input: 240-Volts AC (47 - 63Hz )

Output: 15.0-Volts DC & 1.6A

软件

Windows XP/VISTA/Win7/Win8.1/Win10 (both 32/64bit)

SM32Pro (free with spectrometer)
Includes DLL libraries and SDKs for easy custom application development

尺寸

6.81L x 4.72W x 3.86H inches

重量

5.5lbs

暗噪声 RMS

~20 RMS counts in 16bit (after balancing)

触发模式

Free Run Mode
External 触发模式

滤波器选择

n/a

探测器s

G9204-512

G9206-512

G9208-512

G9206-256

G9208-256

光谱响应范围 (µm)

0.9 - 1.7

0.9 - 2.2

0.9 - 2.5

0.9 - 2.05

0.9 - 2.5

像素尺寸

25 x 500µm

25 x 250µm

25 x 250µm

50 x 500µm

50 x 500µm

光学分辨率

 >3nm overall

 >5nm overall

 >6.5nm overall

 >7nm overall

 >9nm overall

信噪比

 >15,000:1 @100ms

 >10,000:1 @100ms

 >10,000:1 @100ms

 >10,000:1 @100ms

 >7,500:1 @100ms

暗噪声 RMS

6RMS @100ms

6RMS @100ms

16RMS @10ms

6RMS @100ms

8RMS @10ms

光纤接口

SMA905 or FC standard

杂散光

< 0.01% @632nm (< 0.05% avg)

最小积分时间

1ms

触发模式

Free Run mode
软件 触发模式
External 触发模式
TTL Edge Trigger input/digital output for monitoring

滤波器选择

Longpass filter or linear variable filter installed per wavelength coverage

电脑接口

USB 1.1 / 2.0 16-bit (0 - 65535), support up to 8 multi-channel configuration

软件

Windows XP/VISTA/Win7, 8.1, 10 (32/64bit)
SM32Pro & SM32Pro MX (free with spectrometer)

Includes DLL libraries and SDKs for easy custom application development

尺寸(inches)

6.81H x 4.72W x 2.95D inches

重量

4.5lbs

狭缝的选择

10, 25, 50, 100, 200, and 400µm

TEC制冷温度

-10°C
