Title

特性nd1.50137νd56.41ne1.50349νe56.15nF-nC0.008888nF'-nC'0.008967

折射率

特性	λ [nm]
n2,325.4	2,325.4	1.47507
n1,970.1	1,970.1	1.48008
n1,529.6	1,529.6	1.48536
n1,060.0	1,060.0	1.49076
nt	1,014.0	1.49137
ns	852.1	1.49389
nr	706.5	1.49713
nC	656.3	1.49867
nC'	643.8	1.49910

特性	λ [nm]
n632.8	632.8	1.49950
nD	589.3	1.50129
nd	587.6	1.50137
ne	546.1	1.50349
nF	486.1	1.50756
nF'	480.0	1.50807
ng	435.8	1.51243
nh	404.7	1.51649
ni	365.0	1.52350

特性	λ [nm]
n334.1	334.1	1.53120
n312.6	312.6	1.53844
n296.7	296.7
n280.4	280.4
n248.3	248.3

内部透射率

特性	λ [nm]
τ25/2500	2,500	0.520
τ25/2325	2,325	0.630
τ25/1970	1,970	0.850
τ25/1530	1,530	0.983
τ25/1060	1,060	0.996
τ25/700	700	0.997
τ25/660	660	0.994
τ25/620	620	0.993
τ25/580	580	0.993
τ25/546	546	0.992
τ25/500	500	0.991
τ25/460	460	0.990
τ25/436	436	0.988
τ25/420	420	0.988
τ25/405	405	0.987
τ25/400	400	0.986
τ25/390	390	0.982
τ25/380	380	0.973
τ25/370	370	0.966
τ25/365	365	0.958
τ25/350	350	0.910
τ25/334	334	0.720
τ25/320	320	0.310
τ25/310	310	0.130
τ25/300	300	0.020
τ25/290	290
τ25/280	280
τ25/270	270
τ25/260	260
τ25/250	250

特性	λ [nm]
τ10/2500	2,500	0.770
τ10/2325	2,325	0.831
τ10/1970	1,970	0.937
τ10/1530	1,530	0.993
τ10/1060	1,060	0.998
τ10/700	700	0.999
τ10/660	660	0.998
τ10/620	620	0.997
τ10/580	580	0.997
τ10/546	546	0.997
τ10/500	500	0.996
τ10/460	460	0.996
τ10/436	436	0.995
τ10/420	420	0.995
τ10/405	405	0.995
τ10/400	400	0.994
τ10/390	390	0.993
τ10/380	380	0.989
τ10/370	370	0.986
τ10/365	365	0.983
τ10/350	350	0.963
τ10/334	334	0.877
τ10/320	320	0.626
τ10/310	310	0.370
τ10/300	300	0.140
τ10/290	290
τ10/280	280
τ10/270	270
τ10/260	260
τ10/250	250

特性
Ps,t	0.2835
PC,s	0.5385
Pd,C	0.3037
Pe,d	0.2382
Pg,F	0.5475
Pi,h	0.7888
P's,t	0.2810
P'C',s	0.5817
P'd,C'	0.2531
P'e,d	0.2362
P'g,F'	0.4860
P'i,h	0.7819

特性
ΔPC,t	0.0094
ΔPC,s	0.0041
ΔPF,e	-0.0007
ΔPg,F	-0.0015
ΔPi,g	-0.0048
