Title

特性nd1.54814νd45.75ne1.55099νe45.47nF-nC0.011981nF'-nC'0.012118折射率

特性	λ [nm]
n2,325.4	2,325.4	1.51865
n1,970.1	1,970.1	1.52354
n1,529.6	1,529.6	1.52884
n1,060.0	1,060.0	1.53470
nt	1,014.0	1.53541
ns	852.1	1.53845
nr	706.5	1.54256
nC	656.3	1.54457
nC'	643.8	1.54513

特性	λ [nm]
n632.8	632.8	1.54566
nD	589.3	1.54803
nd	587.6	1.54814
ne	546.1	1.55099
nF	486.1	1.55655
nF'	480.0	1.55725
ng	435.8	1.56333
nh	404.7	1.56911
ni	365.0	1.57932

特性	λ [nm]
n334.1	334.1	1.59092
n312.6	312.6
n296.7	296.7
n280.4	280.4
n248.3	248.3

内部透射率

特性	λ [nm]
τ25/2500	2,500	0.500
τ25/2325	2,325	0.610
τ25/1970	1,970	0.840
τ25/1530	1,530	0.990
τ25/1060	1,060	0.996
τ25/700	700	0.997
τ25/660	660	0.996
τ25/620	620	0.996
τ25/580	580	0.997
τ25/546	546	0.997
τ25/500	500	0.996
τ25/460	460	0.996
τ25/436	436	0.996
τ25/420	420	0.995
τ25/405	405	0.994
τ25/400	400	0.993
τ25/390	390	0.992
τ25/380	380	0.988
τ25/370	370	0.984
τ25/365	365	0.981
τ25/350	350	0.955
τ25/334	334	0.810
τ25/320	320	0.300
τ25/310	310	0.010
τ25/300	300
τ25/290	290
τ25/280	280
τ25/270	270
τ25/260	260
τ25/250	250

特性	λ [nm]
τ10/2500	2,500	0.758
τ10/2325	2,325	0.821
τ10/1970	1,970	0.933
τ10/1530	1,530	0.996
τ10/1060	1,060	0.998
τ10/700	700	0.999
τ10/660	660	0.998
τ10/620	620	0.998
τ10/580	580	0.999
τ10/546	546	0.999
τ10/500	500	0.998
τ10/460	460	0.998
τ10/436	436	0.998
τ10/420	420	0.998
τ10/405	405	0.998
τ10/400	400	0.997
τ10/390	390	0.997
τ10/380	380	0.995
τ10/370	370	0.994
τ10/365	365	0.992
τ10/350	350	0.982
τ10/334	334	0.919
τ10/320	320	0.618
τ10/310	310	0.240
τ10/300	300	0.024
τ10/290	290	0.002
τ10/280	280
τ10/270	270
τ10/260	260
τ10/250	250

特性
Ps,t	0.2537
PC,s	0.5108
Pd,C	0.2983
Pe,d	0.2376
Pg,F	0.5660
Pi,h	0.8520
P's,t	0.2508
P'C',s	0.5516
P'd,C'	0.2484
P'e,d	0.2349
P'g,F'	0.5017
P'i,h	0.8424

特性
ΔPC,t	0.0025
ΔPC,s	0.0012
ΔPF,e	-0.0003
ΔPg,F	-0.0009
ΔPi,g	-0.0062
