Title

特性
nd	1.70400	νd	39.38
ne	1.70824	νe	39.12
nF-nC	0.017875	nF'-nC'	0.018105

特性	λ [nm]
n2,325.4	2,325.4	1.66373
n1,970.1	1,970.1	1.66988
n1,529.6	1,529.6	1.67667
n1,060.0	1,060.0	1.68453
nt	1,014.0	1.68551
ns	852.1	1.68982
nr	706.5	1.69578
nC	656.3	1.69872
nC'	643.8	1.69955

特性	λ [nm]
n632.8	632.8	1.70033
nD	589.3	1.70384
nd	587.6	1.70400
ne	546.1	1.70824
nF	486.1	1.71659
nF'	480.0	1.71765
ng	435.8	1.72690
nh	404.7	1.73581
ni	365.0	1.75184

特性	λ [nm]
n334.1	334.1
n312.6	312.6
n296.7	296.7
n280.4	280.4
n248.3	248.3

内部透射率

特性	λ [nm]
τ25/2500	2,500	0.450
τ25/2325	2,325	0.670
τ25/1970	1,970	0.900
τ25/1530	1,530	0.970
τ25/1060	1,060	0.985
τ25/700	700	0.970
τ25/660	660	0.955
τ25/620	620	0.949
τ25/580	580	0.949
τ25/546	546	0.950
τ25/500	500	0.940
τ25/460	460	0.920
τ25/436	436	0.900
τ25/420	420	0.880
τ25/405	405	0.840
τ25/400	400	0.820
τ25/390	390	0.750
τ25/380	380	0.610
τ25/370	370	0.370
τ25/365	365	0.220
τ25/350	350
τ25/334	334
τ25/320	320
τ25/310	310
τ25/300	300
τ25/290	290
τ25/280	280
τ25/270	270
τ25/260	260
τ25/250	250

特性	λ [nm]
τ10/2500	2,500	0.727
τ10/2325	2,325	0.852
τ10/1970	1,970	0.959
τ10/1530	1,530	0.988
τ10/1060	1,060	0.994
τ10/700	700	0.988
τ10/660	660	0.982
τ10/620	620	0.979
τ10/580	580	0.979
τ10/546	546	0.980
τ10/500	500	0.976
τ10/460	460	0.967
τ10/436	436	0.959
τ10/420	420	0.950
τ10/405	405	0.933
τ10/400	400	0.924
τ10/390	390	0.891
τ10/380	380	0.821
τ10/370	370	0.672
τ10/365	365	0.546
τ10/350	350	0.090
τ10/334	334
τ10/320	320
τ10/310	310
τ10/300	300
τ10/290	290
τ10/280	280
τ10/270	270
τ10/260	260
τ10/250	250

部分色散

特性
Ps,t	0.2408
PC,s	0.4979
Pd,C	0.2956
Pe,d	0.2372
Pg,F	0.5769
Pi,h	0.8970
P's,t	0.2377
P'C',s	0.5375
P'd,C'	0.2459
P'e,d	0.2342
P'g,F'	0.5110
P'i,h	0.8856

特性
ΔPC,t	0.0069
ΔPC,s	0.0032
ΔPF,e	-0.0004
ΔPg,F	-0.0006
ΔPi,g	0.0012
