特性nd1.52249νd59.48ne1.52458νe59.22nF-nC0.008784nF'-nC'0.008858折射率
| 特性 | λ [nm] |
|---|
| n2,325.4 | 2,325.4 | 1.49656 |
|---|
| n1,970.1 | 1,970.1 | 1.50146 |
|---|
| n1,529.6 | 1,529.6 | 1.50664 |
|---|
| n1,060.0 | 1,060.0 | 1.51197 |
|---|
| nt | 1,014.0 | 1.51257 |
|---|
| ns | 852.1 | 1.51507 |
|---|
| nr | 706.5 | 1.51829 |
|---|
| nC | 656.3 | 1.51982 |
|---|
| nC' | 643.8 | 1.52024 |
|---|
| 特性 | λ [nm] |
|---|
| n632.8 | 632.8 | 1.52064 |
|---|
| nD | 589.3 | 1.52241 |
|---|
| nd | 587.6 | 1.52249 |
|---|
| ne | 546.1 | 1.52458 |
|---|
| nF | 486.1 | 1.52860 |
|---|
| nF' | 480.0 | 1.52910 |
|---|
| ng | 435.8 | 1.53338 |
|---|
| nh | 404.7 | 1.53734 |
|---|
| ni | 365.0 | 1.54412 |
|---|
| 特性 | λ [nm] |
|---|
| n334.1 | 334.1 | 1.55145 |
|---|
| n312.6 | 312.6 | 1.55821 |
|---|
| n296.7 | 296.7 |
|
|---|
| n280.4 | 280.4 |
|
|---|
| n248.3 | 248.3 |
|
|---|
| 特性 | λ [nm] |
|---|
| τ25/2500 | 2,500 | 0.530 |
| τ25/2325 | 2,325 | 0.660 |
| τ25/1970 | 1,970 | 0.870 |
| τ25/1530 | 1,530 | 0.986 |
| τ25/1060 | 1,060 | 0.995 |
| τ25/700 | 700 | 0.994 |
| τ25/660 | 660 | 0.992 |
| τ25/620 | 620 | 0.993 |
| τ25/580 | 580 | 0.995 |
| τ25/546 | 546 | 0.995 |
| τ25/500 | 500 | 0.993 |
| τ25/460 | 460 | 0.991 |
| τ25/436 | 436 | 0.991 |
| τ25/420 | 420 | 0.991 |
| τ25/405 | 405 | 0.989 |
| τ25/400 | 400 | 0.988 |
| τ25/390 | 390 | 0.984 |
| τ25/380 | 380 | 0.977 |
| τ25/370 | 370 | 0.962 |
| τ25/365 | 365 | 0.956 |
| τ25/350 | 350 | 0.880 |
| τ25/334 | 334 | 0.630 |
| τ25/320 | 320 | 0.210 |
| τ25/310 | 310 | 0.020 |
| τ25/300 | 300 |
|
| τ25/290 | 290 |
|
| τ25/280 | 280 |
|
| τ25/270 | 270 |
|
| τ25/260 | 260 |
|
| τ25/250 | 250 |
|
| 特性 | λ [nm] |
|---|
| τ10/2500 | 2,500 | 0.776 |
| τ10/2325 | 2,325 | 0.847 |
| τ10/1970 | 1,970 | 0.946 |
| τ10/1530 | 1,530 | 0.994 |
| τ10/1060 | 1,060 | 0.998 |
| τ10/700 | 700 | 0.998 |
| τ10/660 | 660 | 0.997 |
| τ10/620 | 620 | 0.997 |
| τ10/580 | 580 | 0.998 |
| τ10/546 | 546 | 0.998 |
| τ10/500 | 500 | 0.997 |
| τ10/460 | 460 | 0.996 |
| τ10/436 | 436 | 0.996 |
| τ10/420 | 420 | 0.996 |
| τ10/405 | 405 | 0.996 |
| τ10/400 | 400 | 0.995 |
| τ10/390 | 390 | 0.994 |
| τ10/380 | 380 | 0.991 |
| τ10/370 | 370 | 0.985 |
| τ10/365 | 365 | 0.982 |
| τ10/350 | 350 | 0.950 |
| τ10/334 | 334 | 0.831 |
| τ10/320 | 320 | 0.536 |
| τ10/310 | 310 | 0.221 |
| τ10/300 | 300 | 0.058 |
| τ10/290 | 290 |
|
| τ10/280 | 280 |
|
| τ10/270 | 270 |
|
| τ10/260 | 260 |
|
| τ10/250 | 250 |
|
| 特性 |
|---|
| Ps,t | 0.2843 |
|---|
| PC,s | 0.5404 |
|---|
| Pd,C | 0.3044 |
|---|
| Pe,d | 0.2384 |
|---|
| Pg,F | 0.5438 |
|---|
| Pi,h | 0.7717 |
|---|
| P's,t | 0.2819 |
|---|
| P'C',s | 0.5839 |
|---|
| P'd,C' | 0.2538 |
|---|
| P'e,d | 0.2364 |
|---|
| P'g,F' | 0.4828 |
|---|
| P'i,h | 0.7653 |
|---|
| 特性 |
|---|
| ΔPC,t | -0.0025 |
|---|
| ΔPC,s | -0.0012 |
|---|
| ΔPF,e | 0.0001 |
|---|
| ΔPg,F | 0.0000 |
|---|
| ΔPi,g | -0.0019 |
|---|
