Title

特性nd1.55836νd54.01ne1.56082νe53.83nF-nC0.010338nF'-nC'0.010418折射率

特性	λ [nm]
n2,325.4	2,325.4	1.52239
n1,970.1	1,970.1	1.53011
n1,529.6	1,529.6	1.53798
n1,060.0	1,060.0	1.54546
nt	1,014.0	1.54625
ns	852.1	1.54944
nr	706.5	1.55337
nC	656.3	1.55519
nC'	643.8	1.55570

特性	λ [nm]
n632.8	632.8	1.55617
nD	589.3	1.55827
nd	587.6	1.55836
ne	546.1	1.56082
nF	486.1	1.56553
nF'	480.0	1.56612
ng	435.8	1.57114
nh	404.7	1.57580
ni	365.0	1.58382

特性	λ [nm]
n334.1	334.1	1.59259
n312.6	312.6
n296.7	296.7
n280.4	280.4
n248.3	248.3

内部透射率

特性	λ [nm]
τ25/2500	2,500	0.040
τ25/2325	2,325	0.260
τ25/1970	1,970	0.800
τ25/1530	1,530	0.940
τ25/1060	1,060	0.991
τ25/700	700	0.996
τ25/660	660	0.994
τ25/620	620	0.994
τ25/580	580	0.994
τ25/546	546	0.994
τ25/500	500	0.992
τ25/460	460	0.987
τ25/436	436	0.981
τ25/420	420	0.975
τ25/405	405	0.967
τ25/400	400	0.963
τ25/390	390	0.950
τ25/380	380	0.930
τ25/370	370	0.910
τ25/365	365	0.890
τ25/350	350	0.800
τ25/334	334	0.590
τ25/320	320	0.240
τ25/310	310	0.030
τ25/300	300
τ25/290	290
τ25/280	280
τ25/270	270
τ25/260	260
τ25/250	250

特性	λ [nm]
τ10/2500	2,500	0.276
τ10/2325	2,325	0.583
τ10/1970	1,970	0.915
τ10/1530	1,530	0.976
τ10/1060	1,060	0.996
τ10/700	700	0.998
τ10/660	660	0.998
τ10/620	620	0.998
τ10/580	580	0.998
τ10/546	546	0.998
τ10/500	500	0.997
τ10/460	460	0.995
τ10/436	436	0.992
τ10/420	420	0.990
τ10/405	405	0.987
τ10/400	400	0.985
τ10/390	390	0.980
τ10/380	380	0.971
τ10/370	370	0.963
τ10/365	365	0.954
τ10/350	350	0.915
τ10/334	334	0.810
τ10/320	320	0.565
τ10/310	310	0.246
τ10/300	300	0.012
τ10/290	290
τ10/280	280
τ10/270	270
τ10/260	260
τ10/250	250

部分色散

特性
Ps,t	0.3080
PC,s	0.5568
Pd,C	0.3061
Pe,d	0.2383
Pg,F	0.5419
Pi,h	0.7758
P's,t	0.3056
P'C',s	0.6011
P'd,C'	0.2552
P'e,d	0.2365
P'g,F'	0.4814
P'i,h	0.7699

特性
ΔPC,t	0.0636
ΔPC,s	0.0280
ΔPF,e	-0.0044
ΔPg,F	-0.0111
ΔPi,g	-0.0440
