特性nd1.72047νd34.70ne1.72539νe34.47nF-nC0.020763nF'-nC'0.021046折射率

特性	λ [nm]
n2,325.4	2,325.4	1.67524
n1,970.1	1,970.1	1.68193
n1,529.6	1,529.6	1.68939
n1,060.0	1,060.0	1.69816
nt	1,014.0	1.69927
ns	852.1	1.70416
nr	706.5	1.71099
nC	656.3	1.71437
nC'	643.8	1.71532

特性	λ [nm]
n632.8	632.8	1.71622
nD	589.3	1.72029
nd	587.6	1.72047
ne	546.1	1.72539
nF	486.1	1.73513
nF'	480.0	1.73637
ng	435.8	1.74724
nh	404.7	1.75777
ni	365.0	1.77690

特性	λ [nm]
n334.1	334.1
n312.6	312.6
n296.7	296.7
n280.4	280.4
n248.3	248.3

内部透射率

特性	λ [nm]
τ25/2500	2,500	0.510
τ25/2325	2,325	0.700
τ25/1970	1,970	0.920
τ25/1530	1,530	0.983
τ25/1060	1,060	0.999
τ25/700	700	0.996
τ25/660	660	0.995
τ25/620	620	0.995
τ25/580	580	0.995
τ25/546	546	0.993
τ25/500	500	0.985
τ25/460	460	0.971
τ25/436	436	0.955
τ25/420	420	0.940
τ25/405	405	0.920
τ25/400	400	0.910
τ25/390	390	0.870
τ25/380	380	0.820
τ25/370	370	0.740
τ25/365	365	0.680
τ25/350	350	0.360
τ25/334	334	0.010
τ25/320	320
τ25/310	310
τ25/300	300
τ25/290	290
τ25/280	280
τ25/270	270
τ25/260	260
τ25/250	250

特性	λ [nm]
τ10/2500	2,500	0.764
τ10/2325	2,325	0.867
τ10/1970	1,970	0.967
τ10/1530	1,530	0.993
τ10/1060	1,060	0.999
τ10/700	700	0.998
τ10/660	660	0.998
τ10/620	620	0.998
τ10/580	580	0.998
τ10/546	546	0.997
τ10/500	500	0.994
τ10/460	460	0.988
τ10/436	436	0.982
τ10/420	420	0.976
τ10/405	405	0.967
τ10/400	400	0.963
τ10/390	390	0.946
τ10/380	380	0.924
τ10/370	370	0.887
τ10/365	365	0.857
τ10/350	350	0.665
τ10/334	334	0.141
τ10/320	320	0.042
τ10/310	310	0.000
τ10/300	300
τ10/290	290
τ10/280	280
τ10/270	270
τ10/260	260
τ10/250	250

部分色散

特性
Ps,t	0.2353
PC,s	0.4916
Pd,C	0.2940
Pe,d	0.2369
Pg,F	0.5833
Pi,h	0.9212
P's,t	0.2322
P'C',s	0.5305
P'd,C'	0.2445
P'e,d	0.2337
P'g,F'	0.5165
P'i,h	0.9088

特性
ΔPC,t	0.0173
ΔPC,s	0.0078
ΔPF,e	-0.0011
ΔPg,F	-0.0021
ΔPi,g	-0.0048
