Title

特性
nd	1.75500	νd	52.30
ne	1.75844	νe	52.07
nF-nC	0.014436	nF'-nC'	0.014566

折射率

特性	λ [nm]
n2,325.4	2,325.4	1.71387
n1,970.1	1,970.1	1.72155
n1,529.6	1,529.6	1.72962
n1,060.0	1,060.0	1.73796
nt	1,014.0	1.73892
ns	852.1	1.74292
nr	706.5	1.74814
nC	656.3	1.75062
nC'	643.8	1.75132

特性	λ [nm]
n632.8	632.8	1.75197
nD	589.3	1.75487
nd	587.6	1.75500
ne	546.1	1.75844
nF	486.1	1.76506
nF'	480.0	1.76589
ng	435.8	1.77296
nh	404.7	1.77954
ni	365.0	1.79082

特性	λ [nm]
n334.1	334.1	1.80306
n312.6	312.6	1.81436
n296.7	296.7	1.82471
n280.4	280.4
n248.3	248.3

内部透射率

特性	λ [nm]
τ25/2500	2,500	0.100
τ25/2325	2,325	0.380
τ25/1970	1,970	0.850
τ25/1530	1,530	0.963
τ25/1060	1,060	0.995
τ25/700	700	0.995
τ25/660	660	0.994
τ25/620	620	0.993
τ25/580	580	0.994
τ25/546	546	0.995
τ25/500	500	0.993
τ25/460	460	0.986
τ25/436	436	0.979
τ25/420	420	0.971
τ25/405	405	0.956
τ25/400	400	0.950
τ25/390	390	0.930
τ25/380	380	0.890
τ25/370	370	0.830
τ25/365	365	0.790
τ25/350	350	0.610
τ25/334	334	0.350
τ25/320	320	0.140
τ25/310	310	0.030
τ25/300	300	0.010
τ25/290	290
τ25/280	280
τ25/270	270
τ25/260	260
τ25/250	250

特性	λ [nm]
τ10/2500	2,500	0.398
τ10/2325	2,325	0.679
τ10/1970	1,970	0.937
τ10/1530	1,530	0.985
τ10/1060	1,060	0.998
τ10/700	700	0.998
τ10/660	660	0.998
τ10/620	620	0.997
τ10/580	580	0.998
τ10/546	546	0.998
τ10/500	500	0.997
τ10/460	460	0.994
τ10/436	436	0.992
τ10/420	420	0.988
τ10/405	405	0.982
τ10/400	400	0.980
τ10/390	390	0.971
τ10/380	380	0.954
τ10/370	370	0.928
τ10/365	365	0.910
τ10/350	350	0.821
τ10/334	334	0.657
τ10/320	320	0.455
τ10/310	310	0.283
τ10/300	300	0.217
τ10/290	290	0.118
τ10/280	280	0.022
τ10/270	270
τ10/260	260
τ10/250	250

部分色散

特性
Ps,t	0.2768
PC,s	0.5337
Pd,C	0.3032
Pe,d	0.2383
Pg,F	0.5473
Pi,h	0.7813
P's,t	0.2744
P'C',s	0.5767
P'd,C'	0.2527
P'e,d	0.2362
P'g,F'	0.4857
P'i,h	0.7743

特性
ΔPC,t	0.0175
ΔPC,s	0.0089
ΔPF,e	-0.0024
ΔPg,F	-0.0085
ΔPi,g	-0.0484
