特性nd1.88300νd40.76ne1.88815νe40.52nF-nC0.021663nF'-nC'0.021921

折射率

特性	λ [nm]
n2,325.4	2,325.4	1.83590
n1,970.1	1,970.1	1.84267
n1,529.6	1,529.6	1.85026
n1,060.0	1,060.0	1.85937
nt	1,014.0	1.86054
ns	852.1	1.86572
nr	706.5	1.87298
nC	656.3	1.87656
nC'	643.8	1.87757

特性	λ [nm]
n632.8	632.8	1.87853
nD	589.3	1.88281
nd	587.6	1.88300
ne	546.1	1.88815
nF	486.1	1.89822
nF'	480.0	1.89950
ng	435.8	1.91050
nh	404.7	1.92093
ni	365.0	1.93920

特性	λ [nm]
n334.1	334.1
n312.6	312.6
n296.7	296.7
n280.4	280.4
n248.3	248.3

内部透射率

特性	λ [nm]
τ25/2500	2,500	0.323
τ25/2325	2,325	0.616
τ25/1970	1,970	0.910
τ25/1530	1,530	0.983
τ25/1060	1,060	0.995
τ25/700	700	0.992
τ25/660	660	0.991
τ25/620	620	0.990
τ25/580	580	0.990
τ25/546	546	0.990
τ25/500	500	0.978
τ25/460	460	0.950
τ25/436	436	0.927
τ25/420	420	0.903
τ25/405	405	0.862
τ25/400	400	0.841
τ25/390	390	0.780
τ25/380	380	0.685
τ25/370	370	0.540
τ25/365	365	0.453
τ25/350	350	0.166
τ25/334	334	0.006
τ25/320	320
τ25/310	310
τ25/300	300
τ25/290	290
τ25/280	280
τ25/270	270
τ25/260	260
τ25/250	250

特性	λ [nm]
τ10/2500	2,500	0.636
τ10/2325	2,325	0.824
τ10/1970	1,970	0.963
τ10/1530	1,530	0.993
τ10/1060	1,060	0.998
τ10/700	700	0.997
τ10/660	660	0.996
τ10/620	620	0.996
τ10/580	580	0.996
τ10/546	546	0.996
τ10/500	500	0.991
τ10/460	460	0.980
τ10/436	436	0.970
τ10/420	420	0.960
τ10/405	405	0.942
τ10/400	400	0.933
τ10/390	390	0.905
τ10/380	380	0.860
τ10/370	370	0.782
τ10/365	365	0.729
τ10/350	350	0.488
τ10/334	334	0.129
τ10/320	320	0.060
τ10/310	310	0.001
τ10/300	300
τ10/290	290
τ10/280	280
τ10/270	270
τ10/260	260
τ10/250	250

部分色散

特性
Ps,t	0.2391
PC,s	0.5004
Pd,C	0.2972
Pe,d	0.2377
Pg,F	0.5667
Pi,h	0.8436
P's,t	0.2363
P'C',s	0.5407
P'd,C'	0.2475
P'e,d	0.2349
P'g,F'	0.5021
P'i,h	0.8337

特性
ΔPC,t	0.0012
ΔPC,s	0.0025
ΔPF,e	-0.0019
ΔPg,F	-0.0085
ΔPi,g	-0.0575
