特性nd1.80107νd34.97ne1.80650νe34.72nF-nC0.022905nF'-nC'0.023227折射率
| 特性 | λ [nm] |
|---|
| n2,325.4 | 2,325.4 | 1.75487 |
|---|
| n1,970.1 | 1,970.1 | 1.76104 |
|---|
| n1,529.6 | 1,529.6 | 1.76809 |
|---|
| n1,060.0 | 1,060.0 | 1.77689 |
|---|
| nt | 1,014.0 | 1.77805 |
|---|
| ns | 852.1 | 1.78325 |
|---|
| nr | 706.5 | 1.79066 |
|---|
| nC | 656.3 | 1.79436 |
|---|
| nC' | 643.8 | 1.79541 |
|---|
| 特性 | λ [nm] |
|---|
| n632.8 | 632.8 | 1.79640 |
|---|
| nD | 589.3 | 1.80087 |
|---|
| nd | 587.6 | 1.80107 |
|---|
| ne | 546.1 | 1.80650 |
|---|
| nF | 486.1 | 1.81726 |
|---|
| nF' | 480.0 | 1.81864 |
|---|
| ng | 435.8 | 1.83068 |
|---|
| nh | 404.7 | 1.84237 |
|---|
| ni | 365.0 |
|
|---|
| 特性 | λ [nm] |
|---|
| n334.1 | 334.1 |
|
|---|
| n312.6 | 312.6 |
|
|---|
| n296.7 | 296.7 |
|
|---|
| n280.4 | 280.4 |
|
|---|
| n248.3 | 248.3 |
|
|---|
内部透射率
| 特性 | λ [nm] |
|---|
| τ25/2500 | 2,500 | 0.581 |
| τ25/2325 | 2,325 | 0.724 |
| τ25/1970 | 1,970 | 0.932 |
| τ25/1530 | 1,530 | 0.988 |
| τ25/1060 | 1,060 | 0.997 |
| τ25/700 | 700 | 0.990 |
| τ25/660 | 660 | 0.987 |
| τ25/620 | 620 | 0.984 |
| τ25/580 | 580 | 0.986 |
| τ25/546 | 546 | 0.982 |
| τ25/500 | 500 | 0.958 |
| τ25/460 | 460 | 0.915 |
| τ25/436 | 436 | 0.870 |
| τ25/420 | 420 | 0.820 |
| τ25/405 | 405 | 0.720 |
| τ25/400 | 400 | 0.680 |
| τ25/390 | 390 | 0.550 |
| τ25/380 | 380 | 0.370 |
| τ25/370 | 370 | 0.150 |
| τ25/365 | 365 | 0.060 |
| τ25/350 | 350 |
|
| τ25/334 | 334 |
|
| τ25/320 | 320 |
|
| τ25/310 | 310 |
|
| τ25/300 | 300 |
|
| τ25/290 | 290 |
|
| τ25/280 | 280 |
|
| τ25/270 | 270 |
|
| τ25/260 | 260 |
|
| τ25/250 | 250 |
|
| 特性 | λ [nm] |
|---|
| τ10/2500 | 2,500 | 0.805 |
| τ10/2325 | 2,325 | 0.879 |
| τ10/1970 | 1,970 | 0.972 |
| τ10/1530 | 1,530 | 0.995 |
| τ10/1060 | 1,060 | 0.999 |
| τ10/700 | 700 | 0.996 |
| τ10/660 | 660 | 0.995 |
| τ10/620 | 620 | 0.994 |
| τ10/580 | 580 | 0.994 |
| τ10/546 | 546 | 0.993 |
| τ10/500 | 500 | 0.983 |
| τ10/460 | 460 | 0.965 |
| τ10/436 | 436 | 0.946 |
| τ10/420 | 420 | 0.924 |
| τ10/405 | 405 | 0.877 |
| τ10/400 | 400 | 0.857 |
| τ10/390 | 390 | 0.787 |
| τ10/380 | 380 | 0.672 |
| τ10/370 | 370 | 0.476 |
| τ10/365 | 365 | 0.336 |
| τ10/350 | 350 | 0.012 |
| τ10/334 | 334 |
|
| τ10/320 | 320 |
|
| τ10/310 | 310 |
|
| τ10/300 | 300 |
|
| τ10/290 | 290 |
|
| τ10/280 | 280 |
|
| τ10/270 | 270 |
|
| τ10/260 | 260 |
|
| τ10/250 | 250 |
|
| 特性 |
|---|
| Ps,t | 0.2268 |
|---|
| PC,s | 0.4849 |
|---|
| Pd,C | 0.2930 |
|---|
| Pe,d | 0.2368 |
|---|
| Pg,F | 0.5859 |
|---|
| Pi,h |
|
|---|
| P's,t | 0.2237 |
|---|
| P'C',s | 0.5235 |
|---|
| P'd,C' | 0.2437 |
|---|
| P'e,d | 0.2336 |
|---|
| P'g,F' | 0.5186 |
|---|
| P'i,h |
|
|---|
| 特性 |
|---|
| ΔPC,t | 0.0009 |
|---|
| ΔPC,s | 0.0005 |
|---|
| ΔPF,e | 0.0001 |
|---|
| ΔPg,F | 0.0009 |
|---|
| ΔPi,g |
|
|---|
