特性nd1.49700νd81.61ne1.49845νe81.21nF-nC0.006090nF'-nC'0.006138折射率
| 特性 | λ [nm] |
|---|
| n2,325.4 | 2,325.4 | 1.47966 |
|---|
| n1,970.1 | 1,970.1 | 1.48279 |
|---|
| n1,529.6 | 1,529.6 | 1.48616 |
|---|
| n1,060.0 | 1,060.0 | 1.48971 |
|---|
| nt | 1,014.0 | 1.49012 |
|---|
| ns | 852.1 | 1.49184 |
|---|
| nr | 706.5 | 1.49408 |
|---|
| nC | 656.3 | 1.49514 |
|---|
| nC' | 643.8 | 1.49544 |
|---|
| 特性 | λ [nm] |
|---|
| n632.8 | 632.8 | 1.49571 |
|---|
| nD | 589.3 | 1.49695 |
|---|
| nd | 587.6 | 1.49700 |
|---|
| ne | 546.1 | 1.49845 |
|---|
| nF | 486.1 | 1.50123 |
|---|
| nF' | 480.0 | 1.50157 |
|---|
| ng | 435.8 | 1.50450 |
|---|
| nh | 404.7 | 1.50720 |
|---|
| ni | 365.0 | 1.51175 |
|---|
| 特性 | λ [nm] |
|---|
| n334.1 | 334.1 | 1.51658 |
|---|
| n312.6 | 312.6 | 1.52096 |
|---|
| n296.7 | 296.7 | 1.52489 |
|---|
| n280.4 | 280.4 |
|
|---|
| n248.3 | 248.3 |
|
|---|
| 特性 | λ [nm] |
|---|
| τ25/2500 | 2,500 | 0.967 |
| τ25/2325 | 2,325 | 0.978 |
| τ25/1970 | 1,970 | 0.990 |
| τ25/1530 | 1,530 | 0.994 |
| τ25/1060 | 1,060 | 0.994 |
| τ25/700 | 700 | 0.993 |
| τ25/660 | 660 | 0.993 |
| τ25/620 | 620 | 0.995 |
| τ25/580 | 580 | 0.997 |
| τ25/546 | 546 | 0.997 |
| τ25/500 | 500 | 0.996 |
| τ25/460 | 460 | 0.992 |
| τ25/436 | 436 | 0.990 |
| τ25/420 | 420 | 0.990 |
| τ25/405 | 405 | 0.992 |
| τ25/400 | 400 | 0.992 |
| τ25/390 | 390 | 0.992 |
| τ25/380 | 380 | 0.989 |
| τ25/370 | 370 | 0.980 |
| τ25/365 | 365 | 0.970 |
| τ25/350 | 350 | 0.880 |
| τ25/334 | 334 | 0.630 |
| τ25/320 | 320 | 0.300 |
| τ25/310 | 310 | 0.120 |
| τ25/300 | 300 | 0.040 |
| τ25/290 | 290 | 0.010 |
| τ25/280 | 280 |
|
| τ25/270 | 270 |
|
| τ25/260 | 260 |
|
| τ25/250 | 250 |
|
| 特性 | λ [nm] |
|---|
| τ10/2500 | 2,500 | 0.987 |
| τ10/2325 | 2,325 | 0.991 |
| τ10/1970 | 1,970 | 0.996 |
| τ10/1530 | 1,530 | 0.998 |
| τ10/1060 | 1,060 | 0.998 |
| τ10/700 | 700 | 0.997 |
| τ10/660 | 660 | 0.997 |
| τ10/620 | 620 | 0.998 |
| τ10/580 | 580 | 0.999 |
| τ10/546 | 546 | 0.999 |
| τ10/500 | 500 | 0.998 |
| τ10/460 | 460 | 0.997 |
| τ10/436 | 436 | 0.996 |
| τ10/420 | 420 | 0.996 |
| τ10/405 | 405 | 0.997 |
| τ10/400 | 400 | 0.997 |
| τ10/390 | 390 | 0.997 |
| τ10/380 | 380 | 0.996 |
| τ10/370 | 370 | 0.992 |
| τ10/365 | 365 | 0.988 |
| τ10/350 | 350 | 0.950 |
| τ10/334 | 334 | 0.831 |
| τ10/320 | 320 | 0.618 |
| τ10/310 | 310 | 0.428 |
| τ10/300 | 300 | 0.250 |
| τ10/290 | 290 | 0.120 |
| τ10/280 | 280 | 0.044 |
| τ10/270 | 270 | 0.014 |
| τ10/260 | 260 |
|
| τ10/250 | 250 |
|
| 特性 |
|---|
| Ps,t | 0.2819 |
|---|
| PC,s | 0.5417 |
|---|
| Pd,C | 0.3055 |
|---|
| Pe,d | 0.2388 |
|---|
| Pg,F | 0.5377 |
|---|
| Pi,h | 0.7470 |
|---|
| P's,t | 0.2797 |
|---|
| P'C',s | 0.5858 |
|---|
| P'd,C' | 0.2548 |
|---|
| P'e,d | 0.2369 |
|---|
| P'g,F' | 0.4774 |
|---|
| P'i,h | 0.7412 |
|---|
| 特性 |
|---|
| ΔPC,t | -0.1084 |
|---|
| ΔPC,s | -0.0514 |
|---|
| ΔPF,e | 0.0103 |
|---|
| ΔPg,F | 0.0311 |
|---|
| ΔPi,g | 0.1497 |
|---|
