特性
nd	1.61800	νd	63.39
ne	1.62033	νe	63.10
nF-nC	0.009749	nF'-nC'	0.009831

特性	λ [nm]
n2,325.4	2,325.4	1.59015
n1,970.1	1,970.1	1.59528
n1,529.6	1,529.6	1.60073
n1,060.0	1,060.0	1.60641
nt	1,014.0	1.60706
ns	852.1	1.60979
nr	706.5	1.61334
nC	656.3	1.61503
nC'	643.8	1.61550

特性	λ [nm]
n632.8	632.8	1.61595
nD	589.3	1.61791
nd	587.6	1.61800
ne	546.1	1.62033
nF	486.1	1.62478
nF'	480.0	1.62534
ng	435.8	1.63007
nh	404.7	1.63445
ni	365.0	1.64190

特性	λ [nm]
n334.1	334.1	1.64991
n312.6	312.6	1.65724
n296.7	296.7	1.66390
n280.4	280.4
n248.3	248.3

内部透射率

特性	λ [nm]
τ25/2500	2,500	0.290
τ25/2325	2,325	0.510
τ25/1970	1,970	0.800
τ25/1530	1,530	0.956
τ25/1060	1,060	0.994
τ25/700	700	0.994
τ25/660	660	0.993
τ25/620	620	0.992
τ25/580	580	0.994
τ25/546	546	0.995
τ25/500	500	0.992
τ25/460	460	0.986
τ25/436	436	0.982
τ25/420	420	0.979
τ25/405	405	0.970
τ25/400	400	0.964
τ25/390	390	0.940
τ25/380	380	0.900
τ25/370	370	0.830
τ25/365	365	0.780
τ25/350	350	0.530
τ25/334	334	0.200
τ25/320	320	0.030
τ25/310	310
τ25/300	300
τ25/290	290
τ25/280	280
τ25/270	270
τ25/260	260
τ25/250	250

特性	λ [nm]
τ10/2500	2,500	0.609
τ10/2325	2,325	0.764
τ10/1970	1,970	0.915
τ10/1530	1,530	0.982
τ10/1060	1,060	0.998
τ10/700	700	0.998
τ10/660	660	0.997
τ10/620	620	0.997
τ10/580	580	0.998
τ10/546	546	0.998
τ10/500	500	0.997
τ10/460	460	0.994
τ10/436	436	0.993
τ10/420	420	0.992
τ10/405	405	0.988
τ10/400	400	0.985
τ10/390	390	0.976
τ10/380	380	0.959
τ10/370	370	0.928
τ10/365	365	0.905
τ10/350	350	0.776
τ10/334	334	0.525
τ10/320	320	0.230
τ10/310	310	0.061
τ10/300	300
τ10/290	290
τ10/280	280
τ10/270	270
τ10/260	260
τ10/250	250

部分色散

特性
Ps,t	0.2797
PC,s	0.5380
Pd,C	0.3044
Pe,d	0.2385
Pg,F	0.5424
Pi,h	0.7642
P's,t	0.2774
P'C',s	0.5816
P'd,C'	0.2538
P'e,d	0.2365
P'g,F'	0.4815
P'i,h	0.7578

特性
ΔPC,t	-0.0279
ΔPC,s	-0.0127
ΔPF,e	0.0020
ΔPg,F	0.0052
ΔPi,g	0.0208
