特性
nd	1.60738	νd	56.65
ne	1.60994	νe	56.37
nF-nC	0.010722	nF'-nC'	0.010821

折射率

特性	λ [nm]
n2,325.4	2,325.4	1.57881
n1,970.1	1,970.1	1.58378
n1,529.6	1,529.6	1.58914
n1,060.0	1,060.0	1.59490
nt	1,014.0	1.59558
ns	852.1	1.59847
nr	706.5	1.60230
nC	656.3	1.60414
nC'	643.8	1.60465

特性	λ [nm]
n632.8	632.8	1.60513
nD	589.3	1.60729
nd	587.6	1.60738
ne	546.1	1.60994
nF	486.1	1.61486
nF'	480.0	1.61547
ng	435.8	1.62073
nh	404.7	1.62562
ni	365.0	1.63398

特性	λ [nm]
n334.1	334.1	1.64304
n312.6	312.6
n296.7	296.7
n280.4	280.4
n248.3	248.3

内部透射率

性	λ [nm]
τ25/2500	2,500	0.600
τ25/2325	2,325	0.760
τ25/1970	1,970	0.930
τ25/1530	1,530	0.988
τ25/1060	1,060	0.995
τ25/700	700	0.995
τ25/660	660	0.994
τ25/620	620	0.994
τ25/580	580	0.995
τ25/546	546	0.995
τ25/500	500	0.990
τ25/460	460	0.983
τ25/436	436	0.982
τ25/420	420	0.984
τ25/405	405	0.985
τ25/400	400	0.984
τ25/390	390	0.979
τ25/380	380	0.970
τ25/370	370	0.940
τ25/365	365	0.920
τ25/350	350	0.780
τ25/334	334	0.490
τ25/320	320	0.180
τ25/310	310	0.040
τ25/300	300
τ25/290	290
τ25/280	280
τ25/270	270
τ25/260	260
τ25/250	250

特性	λ [nm]
τ10/2500	2,500	0.815
τ10/2325	2,325	0.896
τ10/1970	1,970	0.971
τ10/1530	1,530	0.995
τ10/1060	1,060	0.998
τ10/700	700	0.998
τ10/660	660	0.998
τ10/620	620	0.998
τ10/580	580	0.998
τ10/546	546	0.998
τ10/500	500	0.996
τ10/460	460	0.993
τ10/436	436	0.993
τ10/420	420	0.994
τ10/405	405	0.994
τ10/400	400	0.994
τ10/390	390	0.992
τ10/380	380	0.988
τ10/370	370	0.976
τ10/365	365	0.967
τ10/350	350	0.905
τ10/334	334	0.752
τ10/320	320	0.504
τ10/310	310	0.276
τ10/300	300	0.102
τ10/290	290	0.020
τ10/280	280
τ10/270	270
τ10/260	260
τ10/250	250

部分色散

特性
Ps,t	0.2690
PC,s	0.5285
Pd,C	0.3027
Pe,d	0.2384
Pg,F	0.5477
Pi,h	0.7802
P's,t	0.2666
P'C',s	0.5713
P'd,C'	0.2523
P'e,d	0.2362
P'g,F'	0.4860
P'i,h	0.7730

特性
ΔPC,t	-0.0162
ΔPC,s	-0.0064
ΔPF,e	0.0003
ΔPg,F	-0.0008
ΔPi,g	-0.0130
