承诺光谱值λs (τi = 0.00001) [nm]510λc (τi = 0.5) [nm]590 ± 6λp1 (τi = 0.92) [nm]660内部透过率（表格）

λ [nm]
200	< 10⁻³
210	< 10⁻³
220	< 10⁻³
230	< 10⁻³
240	< 10⁻³
250	< 10⁻³
260	< 10⁻³
270	< 10⁻³
280	< 10⁻³
290	< 10⁻³
300	< 10⁻³
310	< 10⁻³
320	< 10⁻³
330	< 10⁻³
340	< 10⁻³
350	< 10⁻³
360	< 10⁻³
370	< 10⁻³
380	< 10⁻³
390	< 10⁻³
400	< 10⁻³
410	< 10⁻³
420	< 10⁻³
430	< 10⁻³
440	< 10⁻³
450	< 10⁻³
460	< 10⁻³
470	< 10⁻³
480	< 10⁻³
490	< 10⁻³

λ [nm]
500	< 10⁻³
510	< 10⁻³
520	< 10⁻³
530	< 10⁻³
540	< 10⁻³
550	< 10⁻³
560	< 10⁻³
570	0.006
580	0.121
590	0.515
600	0.823
610	0.933
620	0.966
630	0.975
640	0.979
650	0.980
660	0.980
670	0.979
680	0.978
690	0.977
700	0.976
710	0.975
720	0.973
730	0.972
740	0.970
750	0.969
760	0.967
770	0.965
780	0.963
790	0.962

λ [nm]
800	0.960
810	0.958
820	0.957
830	0.955
840	0.954
850	0.952
860	0.951
870	0.950
880	0.950
890	0.949
900	0.948
910	0.947
920	0.947
930	0.946
940	0.945
950	0.945
960	0.944
970	0.944
980	0.943
990	0.943
1,000	0.943
1,010	0.942
1,020	0.942
1,030	0.942
1,040	0.941
1,050	0.941
1,060	0.941
1,070	0.941
1,080	0.941
1,090	0.941

λ [nm]
1,100	0.941
1,110	0.941
1,120	0.941
1,130	0.941
1,140	0.941
1,150	0.941
1,160	0.941
1,170	0.942
1,180	0.942
1,190	0.942
1,200	0.942
1,250	0.943
1,300	0.946
1,350	0.949
1,400	0.949
1,450	0.955
1,500	0.959
1,550	0.963
1,600	0.966
1,650	0.968
1,700	0.969
1,750	0.968
1,800	0.966
1,850	0.964
1,900	0.962
1,950	0.960
2,000	0.958
2,050	0.955
2,100	0.952
2,150	0.948

λ [nm]
2,200	0.933
2,250	0.929
2,300	0.932
2,350	0.931
2,400	0.927
2,450	0.921
2,500	0.912
2,550	0.902
2,600	0.899
2,650	0.892
2,700	0.834
2,750	0.434
2,800	0.339
2,850	0.338
2,900	0.347
2,950	0.352
3,000	0.345
3,050	0.325
3,100	0.297
3,150	0.265
3,200	0.232
3,250	0.208
3,300	0.190
3,350	0.176
3,400	0.164
3,450	0.157
3,500	0.153
3,550	0.149
3,600	0.147
3,650	0.148

λ [nm]
3,700	0.151
3,750	0.156
3,800	0.162
3,850	0.170
3,900	0.176
3,950	0.181
4,000	0.179
4,050	0.168
4,100	0.148
4,150	0.125
4,200	0.101
4,250	0.077
4,300	0.057
4,350	0.039
4,400	0.022
4,450	0.010
4,500	0.005
4,550	0.002
4,600	< 10⁻³
4,650	< 10⁻³
4,700	< 10⁻³
4,750	< 10⁻³
4,800	< 10⁻³
4,850	< 10⁻³
4,900	< 10⁻³
4,950	< 10⁻³
5,000	< 10⁻³
5,050	< 10⁻³
5,100	< 10⁻³
5,150	< 10⁻³

反射系数
Pd	0.921

参考厚度
d [mm]	3

承诺光谱值
λs (τi = 0.00001) [nm]	510
λc (τi = 0.5) [nm]	590 ± 6
λp1 (τi = 0.92) [nm]	660

折射率 n
ns (852.1 nm) = 1.510
nd (587.6 nm) = 1.510

色度评估

光源	A(Planck T = 2347K)
d [mm]	1	2	3
x	0.639	0.662	0.669
y	0.354	0.338	0.331
Y	39	33	30
λd [nm]	605	609	611
Pe	0.96	1.00	1.00

光源	Planck T = 3200 K
d [mm]	1	2	3
x	0.635	0.660	0.667
y	0.356	0.340	0.332
Y	37	31	28
λd [nm]	604	608	611
Pe	0.95	1.00	1.00

光源	D65 (TC = 6504 K)
d [mm]	1	2	3
x	0.610	0.652	0.661
y	0.361	0.347	0.338
Y	27	22	19
λd [nm]	602	606	609
Pe	0.92	1.00	1.00

物理值

密度
p [g/cm3]	2.56

气泡含量
气泡等级	3

玻转温度
Tg [°C]	506

温度系数
Tk [nm/°C]	0.13

耐化学性
耐污性	0
耐酸性	1.0
耐碱性	1.0

热膨胀
α-30°C/+70°C [10-6/K]	7.9
α20°C/300°C [10-6/K]	9
α20°C/200°C [10-6/K]
